With the Satellite1 Dev Kit, you can create your own ultra-powerful voice assistant, smart speaker, and multi-sensor all in one product — fully compatible with the Home Assistant platform.
All orders placed on Feb. 17th 2026 or later will ship with the latest Satellite1.1 design, featuring the enhancements highlighted below.
Key Features:
- Microphone Processing: High-performance microphones with an XMOS audio processing chip.
- Audio Output: Supports high-quality Snapcast multi-room music playback via the powerful 25W built-in amplifier or headphone jack.
- Controls: 4 programmable tactile buttons, including hardware mute for privacy. 360 degree addressable LED ring.
- Sensors: Monitors room temperature, humidity, luminosity, and human presence (when paired with a mmWave radar sensor). Latest iteration comes with extra LD2450 connector on bottom of Hat board.
- Radios: Built-in 2.4 GHz Wi-Fi and Bluetooth® 5 (LE). Latest iteration comes with external WiFi antenna.
- Expandable: FX23L expansion connector for future accessories.
Processor:
- ESP32-S3: Dual-core 32-bit LX7, running at 240 MHz with 512 KB SRAM, 16 MB Flash, and 8 MB PSRAM.
- Audio Processor: XMOS XU316, 16-core 32-bit RISC running at 800 MHz with 3200 MIPS, 1024 KB SRAM, and 8 MB Flash.
- RPi: Hat board can optionally be powered by Raspberry Pi with FutureProofHomes firmware (experimental)
Audio Output:
- Line-level 3.5mm Headphone Output: PCM5122
- 25W Mono Amplifier Output: TAS2780
Sensors:
- Ambient Light: LTR-303ALS
- Temperature & Humidity: AHT20
- Optional Human Presence Detection: Add your own LD2410 or LD2450 for mmWave radar human presence detection.
Power Requirements:
- Recommend 30W USB-C Power Delivery
- Maximum: Boards support up to 20V @ 5A USB-C Power Delivery
Assembly:
Firmware:
- Firmware is factory installed. Connect to Home Assistant by following steps here.
- Firmware updates arrive over-the-air (OTA) or by using our ESP Web Flasher.
- Modify the firmware by using the ESPHome Dashboard Builder.
Additional Included Components:
- USB-C Power Delivery Adapter & Cable
- WiFi Antenna & IPEX Connector Cable.
Dimensions
Dimensions
When removed from packaging:
Width: 88 mm
Length: 88 mm
Height: 10 mm
Weight
Weight
When removed from packaging:
44 g
